* Outstanding adhesion to many automotive paints and MSE (Medium surface energy) plastics * Operating temperature up to 90°C * Optimized acrylate foam core for easy application and good adaptation to component surfaces * Temperature, weather, UV, and solvent resistance * Acrylic plus tape suitable for all manual and automatic application processes.
Send Inquiry
Products Description
The acrylic plus PT1000 series tape for automotive is made from black acrylic foam and is particularly suitable for attaching automotive components. The special product properties produce a high adhesion on difficult surfaces.
Products Features
• Outstanding adhesion to many automotive paints and MSE (Medium surface energy) plastics.
• Operating temperature up to 90°C.
• Optimized acrylate foam core for easy application and good
adaptation to component surfaces.
• Temperature, weather, UV, and solvent resistance.
• Acrylic plus tape suitable for all manual and automatic application processes.
Products Advantages
• Acrylic foam adhesive tapes can compensate for stress due to their unique viscoelasticity. In contrast to foam adhesive tapes (PE, PU adhesive tapes), can cope with significant elongation differences between substrates in case of temperature changes.
• Easy to use: The automotive acrylic plus attachment tape can be easily processed in multiple ways to cut and apply.
• Immediate initial adhesion: The initial adhesion allows immediate
further processing without temporary support or fixtures.
• Freedom of design: enables the easy differentiation of vehicle models through modified trim attachments without change of the body configuration.
• Sealing and damping properties: improvement of NVH properties.
Products Construction
Physical Properties
| Typical Values | PT1100 | PT1500 |
| Thickness | 1.1 mm | 1.5 mm |
| 90° Peel on Reference Stainless Steel plates (Specification values have to be determined on customer substrate) | ||
| 20 min RT Liner Side (LS) | 35 N/cm | 42 N/cm |
| 20 min RT Non-Liner Side (NLS) | 35 N/cm | 42 N/cm |
| Density | 545 kg/m³ | 521 kg/m³ |
| Core | Acrylic Plus Tape | |
| Color | Grey with Black Adhesive | |
| Liner | F: Red branded polyethylene foil, both sides siliconized. T: Version with one side siliconized red polyethylene foil, good for tabbing tape bonding and an additional, one side siliconized transparent polyethylene liner, to be removed before application. This liner is available for die cuts, level wound rolls, and planetary rolls from 100 mm width upwards. |
|
| Adhesive Liner Side (LS) and Non-Liner Side(NLS) |
Liner Side (LS): VR2 adhesive with very high initial and final tack to paint. Non-Line Side (NLS): VR1 adhesive with very high initial and final tack. |
|
| Shelf Life | Film liner Duration: 24 months from the date of manufacturing Conditions: 4 °C - 38 °C and 0 - 95 % RH in original unopened packaging – optimum: 23 °C ± 2 °C and 50% ± 4 % RH Levelwound rolls are to be stored horizontally. |
|
| Temperature Resistance | -40°C to +90°C, short term 120°C (both values are load-dependent). |
|
| Splices |
Number of splices depends on order quantity and roll length. Level-wound rolls have 3-4 splices on average. Smaller order quantities (less than 400 m²) rolls could contain a significantly different number of splices. |
|
Notice: The above were reference values. For detailed information, please contact HONGFU.
Products Application
Attachment of Exterior Trim and Molding
Automotive acrylic plus tape is often used to securely attach exterior trim pieces, moldings, badges, and emblems to vehicles. The strong adhesive properties of the tape ensure that the trim remains firmly in place even under harsh weather conditions and high-speed driving.
Bonding of Body Side Moldings
Acrylic plus tapes are utilized for bonding body side moldings to the vehicle body. This helps in enhancing the aesthetic appeal of the vehicle while also protecting against dings and dents caused by impacts from other vehicles or objects.
Mounting of Spoilers and Body Kits
Automotive enthusiasts often use Acrylic Plus Tapes to mount spoilers, body kits, and aftermarket accessories onto their vehicles. The tapes provide a strong and durable bond without the need for drilling holes into the vehicle's body, preserving its integrity.
Sealing of Trim and Weatherstripping
These tapes are employed for sealing gaps and joints in automotive trim pieces, weatherstripping, and door seals. By providing a watertight seal, they help prevent water intrusion, reduce wind noise, and improve overall cabin comfort.
Acrylic plus PT1000 series tape for automotive plays a crucial role in automotive assembly and customization, providing strong and reliable bonding solutions for a variety of exterior and interior applications while meeting the stringent performance requirements of the automotive industry.
Products Construction
Physical Properties
| Typical Values | PT1100 | PT1500 |
| Thickness | 1.1 mm | 1.5 mm |
| 90° Peel on Reference Stainless Steel plates (Specification values have to be determined on customer substrate) | ||
| 20 min RT Liner Side (LS) | 35 N/cm | 42 N/cm |
| 20 min RT Non-Liner Side (NLS) | 35 N/cm | 42 N/cm |
| Density | 545 kg/m³ | 521 kg/m³ |
| Core | Acrylic Plus Tape | |
| Color | Grey with Black Adhesive | |
| Liner | F: Red branded polyethylene foil, both sides siliconized. T: Version with one side siliconized red polyethylene foil, good for tabbing tape bonding and an additional, one side siliconized transparent polyethylene liner, to be removed before application. This liner is available for die cuts, level wound rolls, and planetary rolls from 100 mm width upwards. |
|
| Adhesive Liner Side (LS) and Non-Liner Side(NLS) |
Liner Side (LS): VR2 adhesive with very high initial and final tack to paint. Non-Line Side (NLS): VR1 adhesive with very high initial and final tack. |
|
| Shelf Life | Film liner Duration: 24 months from the date of manufacturing Conditions: 4 °C - 38 °C and 0 - 95 % RH in original unopened packaging – optimum: 23 °C ± 2 °C and 50% ± 4 % RH Levelwound rolls are to be stored horizontally. |
|
| Temperature Resistance | -40°C to +90°C, short term 120°C (both values are load-dependent). |
|
| Splices |
Number of splices depends on order quantity and roll length. Level-wound rolls have 3-4 splices on average. Smaller order quantities (less than 400 m²) rolls could contain a significantly different number of splices. |
|
Notice: The above were reference values. For detailed information, please contact HONGFU.
